Daiwa RS 500 Line Capacity & Reel Setup Guide
ReelCalc Reel Setup Guide
Daiwa RS 500 Line Capacity & Reel Setup Guide
This 500-size ultralight starts with a 4 lb / 170-yard US mono rating. Daiwa also publishes exact RS500 millimeter capacities, which make it easier to compare thin lines without treating every 4 lb label as the same thickness. Infinite Anti-Reverse limits backward handle movement. Choose your line below to estimate a full fill, or set a shorter main-line amount and check how much backing fits underneath.
Quick Answer: Best Line for the Daiwa RS 500
Best overall range: 4-8 lb braid
Simple alternative: 2-4 lb mono/fluoro
For most anglers, start with 4-8 lb braid and add a 2-4 lb leader matched to the water and target species. A straightforward alternative is 2-4 lb mono/fluoro.
Who Is the Daiwa RS 500 For?
For ultralight trout and panfish fishing, start with the rod's line range and the cover you expect to fish. ReelCalc's 4-8 lb braid and 2-4 lb mono/fluoro ranges are setup suggestions, not extra manufacturer ratings. Keep an ultralight setup balanced with the rod and small presentations rather than choosing heavier line simply because it fits.
Use the Pre-Loaded RS 500 ReelCalc Calculator
The Daiwa RS 500 is already selected. Capacity Only estimates a full spool; Backing + Main Line lets you choose a working length and estimate the backing beneath it. Both use the diameter of your selected line.
Best Line Setup for the Daiwa RS 500
4 lb braid over monofilament backing with a 2-4 lb leader is a starting suggestion for this reel. You can fill the spool with main line, or use backing beneath a shorter working section. Select the actual line and its listed diameter before deciding how many yards to put on.
| Fishing Use | Suggested Line Setup |
|---|---|
| ultralight trout and panfish fishing | 4 lb braid with a 2-4 lb leader |
| Simple straight-line setup | 2-4 lb mono/fluoro |
Daiwa RS 500 Line Capacity
The table keeps the published pound-test ratings and the verified millimeter ratings separate. ReelCalc uses a verified diameter rating for the matching line material when available, then scales it to your chosen line. A pound-test label alone does not tell you its thickness.
| Line Type | Line Rating | Capacity |
|---|---|---|
| Monofilament | 4 lb | 170 yards |
| Braid | 6 lb | 220 yards |
| Monofilament | 0.16 mm | 160 m (about 175 yd) |
| Braid | 0.06 mm | 200 m (about 219 yd) |
Daiwa RS 500 Specs
These are published specifications for RS500. Retrieve is the listed amount per turn at the rated fill level, not a fixed value as the spool empties. Maximum drag is an upper rating, not the setting to use with every line.
| Specification | Daiwa RS 500 |
|---|---|
| Exact model | RS500 |
| Reel size | 500 |
| Gear ratio | 5.2:1 |
| Line retrieve | 24.8 inches per crank |
| Weight | 5.8 oz |
| Maximum drag | 6.6 lb |
| Bearings | 3+1 |
| Mono capacity | 4 lb / 170 yards |
| Braid capacity | 6 lb / 220 yards |
Specifications checked against Daiwa's official U.S. product specifications.
Sources checked October 12, 2026: Manufacturer product listing; Manufacturer capacity table. Specifications and setup guidance, not a hands-on reel review.
Daiwa RS 500 FAQs
What Size Braid Is Best for the Daiwa RS 500?
Start with 4-8 lb braid, then match the strength to your rod and fishing conditions. For a braid-and-leader setup, choose the leader for the cover and presentation rather than matching the braid label alone. Backing is optional; check that braid is secured against slipping if you tie directly to the spool.
How Much Line Does the Daiwa RS 500 Hold?
Use the factory ratings in the capacity table as reference points, not a promise that every line of that pound test fits the same amount. Select your exact line in the calculator, and watch the reel's fill clearance as you spool under steady tension.
